Allied Telesis AT-S25 - Manual (Page 21)

AT-S25 Version 1.4 User’s Guide
21
Note
The master switch of the stack has the number 1. All other switches
are slave switches. When instructed by this manual to select the
master switch, be sure to select switch number 1.
Selecting Menu
Options and
Changing
Parameters
The table below shows you how to move through and select menu
selections if you are using the DEC VT100 or ANSI (the default) terminal
configuration:
Table 1 DEC VT100 or ANSI Terminal
When directed to You must
Select an option Highlight the option by pressing the Up (
↑
)
or Down (
↓
) arrow key; then press
or
Type the first character of the option you
want at the prompt and then press
.
If two or more options have matching initial
characters, type the initial character enough
times until the option you want is
highlighted; then press .
Enter information Type the information and press .
Return to the previous
screen Select the option that returns you to the
previous menu and press
or
Press .
