22
Table 2 explains how to move through and select menu selections if you
are using a generic (dumb) terminal.
Activated options in menus are preceded by a > symbol. In the following
example, the first option is activated:
> Enable this port
Disable this port
When you press to select a field in which you can enter a value,
the -> symbol is displayed. For example:
System name: ->
The -> symbol indicates that you can enter a value for the parameter or
change the existing value. Once you have entered a value, press
. To delete an existing value to a parameter without assigning a
new value, type a space and press . In most cases, a change to a
parameter is activated on the switch immediately.
Table 2 Generic (Dumb) Terminal
When directed You must
To select an option Type the first character of the option you
want and then press .
If two or more options have matching initial
characters, type enough characters for
Omega to distinguish your choice from the
other options; then press . To
guide you, the characters you must type are
in uppercase.
For example:
Mirroring configuration
MAC Address Table
If options on a list are preceded by numbers
(1:, 2:, 3:, etc.), type the number
corresponding to your choice at the
prompt; then press .
To enter information Type the information at the prompt and
press .
To return to the
previous screen Press after making an entry.
