Omega Main
Menu
Figure 1 illustrates an example of the Omega Main Menu.
Figure 1 Omega Main Menu from a Local Session
The Main Menu is divided into two parts. The top of the Main Menu
contains the menu selections and the bottom part dispalys a list of the
switches in the stack.
The “>” symbol is used in the Main Menu to indicate the currently
selected switch. When you start an Omega session, the default selected
switch is the master switch.
Most of the procedures in this guide start by having you select the
switch in the stack on which you want to perform the procedure. For
example, to display the status of the ports on switch 3, you would first
select switch 3 from the bottom of the Main Menu and then choose Port
status and configuration.
The number of each switch in the menu corresponds to the Stack ID
setting on the switch. The Stack ID setting is assigned with the Stack ID
switch on the back panel of the switch. For the location of the switch and
information on how each switch is assigned a value, refer to the
AT-8316F/MT, AT-8316F/VF, AT-8316F/SC and AT-8324 Installation Guide.
Allied Telesyn AT-8324 Ethernet Switch: 1.4
Main Menu
Port status and configuration
Ethernet statistics
Administration
System configuration
Traffic/Port Mirroring
Virtual LANs/QoS
Bridging
MAC Address Table
Quit
Or select a module:
> 1 - Switch / Master
2 - Switch / Slave
3 - Switch / Slave
4 - Switch / Slave
