64
Displaying Port Status
The Port Status window displays the current operating status of all the
ports on a switch in a stack, including any expansion modules, if
installed. The window enables you to quickly ascertain the operating
status of the ports by displaying a variety of information, such as
whether a link exists between the ports and the end nodes, and whether
any of the ports have been manually disabled.
To display the status of the ports on a switch, perform the following
procedure:
1. From the Main Menu, select the switch whose port status you want to
view.
2. From the Main Menu, select Port Status and Configuration.
The Port Status window in Figure 22 is displayed.
Figure 22 Port Status Window
