110
Assigning the CPU Management Port to a VLAN
This section contains the procedure for assigning the CPU management
port of the master switch to a VLAN. Be default, the management port is
assigned to the VLAN named Default VLAN.
Note
This procedure should be performed with caution. The CPU
management port must be assigned to the same VLAN that contains
the ports to which your remote management stations are
connected. Assigning the management port to a VLAN that does
not contain the ports for your remote management stations will
prevent you from being able to manage the stack remotely.
To assign the CPU port to a VLAN, perform the following procedure:
1. From the Main Menu, select the master switch.
Note
You must select the master switch to perform this procedure. Do not
select a slave switch.
2. From the Main Menu, select Virtual LANs/QoS.
The Virtual LAN/QoS menu in Figure 48 on page 98 is displayed.
3. Select Assign Management Port to VLAN.
The window in Figure 53 is displayed.
Figure 53 VLAN Assignment for CPU Management Port
