32
Menu Tree
Table 3 lists the menu options in the Omega interface. The table includes
a brief function of each selection and the page number of the procedure
where the selection is explained.
Table 3 Omega Menu Tree
Main Menu
Selection Menu
Selection
Page Function
Port Status and Configuration
Port number 64, 66 Displays and configures the parameter settings
for the ports on a switch.
Ethernet Statistics
Transmit
statistics 118 Displays statistics on the number of frames
transmitted by a port or a switch.
Individual port
overview 114, 118 Displays the received and transmitted frame
statistics for a specific port.
RMON
statistics 120 Displays RMON statistics for the entire switch.
Port RMON
statistics 121 Displays RMON statistics by port.
Zero all
statistic
counters on
entire system 122 Returns the statistic counters in a stack to 0
(zero).
Administration
Update
software in
another
system 135 Downloads the stack software from one stack to
another stack.
Broadcast
updated
software to all
systems 136 Downloads the stack software from one stack to
all the other stacks in the network.
Xmodem 133 Downloads the AT-S25 software onto the stack.
Only available via a local session.
