58
Ag Leader Integra and Versa Firmware Version 4.3 / Edge Firmware Version 5.1
6. Enter your Username and Password in the same
manner. When finished, press the check mark button.
The Cell Modem screen reappears and should show
the Status as Connected. If not, check with your cell
carrier to ensure you have entered the correct Access
Point and/or Username and Password.
Note:
A Username and Password is not always required and can often be left blank.
External Radio.The External Radio screen enables you to set the Baud Rate (data transmission rate) of
your radio connection. The external radio is a third party radio used for data transmission and reception.
Note:
Supported signal formats are INX, CMR+, RTCM 2.3 and RTCM V3.x.
To set the radio Baud rate:
1. From the AutoSteer Setup screen, press the
Connections button. The Connections menu appears.
2. From the Connections menu, press the External
Radio button. The External Radio screen appears.
3. Select a port from the right side scrolling list and
press the Change Baud Rate button. The Available
Baud Rates scroll list appears.
Note:
Changing the Baud Rate on the External Radio screen also changes the Baud Rate as
displayed in the NMEA Out screen. See
. Note that Port A can be used
simultaneously for the External Radio and NMEA Out, but both functions must use the same Baud
Rate.
4. Select a baud rate and press the check mark button.
The External Radio screen appears.
5. Press Apply to activate your changes.
