11
• If your job requires an accurate latitude and longitude position, or the ability to repeat or continue a saved
job (Autosteer over the same guidance paths), refer to your Base Station Hardware Manual for additional
information and instructions.
A
UTO
S
TEER
S
ETUP
S
CREEN
O
VERVIEW
The ParaDyme AutoSteer Setup Screen is
accessed from your display. Refer to your display's
User Manual for details.
• The Vehicle menu enables you to configure a vehicle,
set up a new vehicle, manage existing vehicles, perform
the auto calibration of a vehicle, perform the steering
adjustments and manage steering components.
• The System menu enables you to configure and
monitor system parameters.
• The GPS menu provides procedures and detailed
information for selecting and configuring your GPS
correction source and radio options.
• The Connections menu enables you to configure and monitor communication parameters.
• The My Account menu enables you to configure and monitor account parameters.
• To return to the previous screen, press the Back icon. Press the Back icon from the AutoSteer Setup
screen to return to your main application.
B
ASE
S
TATION
If you use a base station, refer to your base station hardware manual for installation and operation
instructions.
LED S
TATUS
Table 3-1 defines the
status of the system as
shown by the LEDs color
configuration.
