HiCommand
®
Dynamic Link Manager (HDLM) for Windows
®
Systems User’s Guide
253
Displayed Item
No Summary
Displayed
1
Summary
Displayed
2
Description
DskName
3
DskName
The storage system name, which identifies the storage system that is accessed by a path.
A storage system name consists of the following three elements, separated by periods:
Vendor ID: The name of the storage system vendor (for example,
HITACHI
).
Product ID: Indicates the storage system product ID, emulation type, or model ID (for
example,
DF600F
). For more details, see Table 7.13.
Serial number: For the Thunder 9200/9500V Series, Lightning 9900/9900V Series
TagmaStore, and Universal Storage Platform V, the serial number of the storage
system (for example,
0051
)
For the EMC DMX series, EMC CX series, and HP EVA series, a hyphen (-) is
displayed.
For the Thunder 9200/9500V Series, Lightning 9900/9900V Series, TagmaStore, and
Universal Storage Platform V, you can identify an actual storage system by referencing
the above information from the storage system management program.
iLU
3
iLU
For the Thunder 9200/9500V Series, Lightning 9900/9900V Series TagmaStore, and
Universal Storage Platform V:
LU number of the storage subsystem.
This number combined with the storage system name (shown in
DskName
) identifies
the LU that is accessed by a path.
For TagmaStore USP, Lightning 9900V Series, and Lightning 9900 Series, the first two
characters of
iLU
are the CU (Control Unit) number, and the last two characters are
the internal LU number within the CU. Indicated by a hexadecimal number. For the
TagmaStore AMS/WMS series, Thunder 9500V Series, and Thunder 9200 Series, the
entire value of
iLU
is the internal LU number within the storage system. You can
identify an actual LU by referencing
iLU
from the storage system management
program.
Indicated by a decimal number. For Universal Storage Platform V, indicated by a
hexadecimal number. The first two characters of
iLU
are the number of the logical
DKC (Disk Controller), the middle two numbers are the CU (Control Unit) number, and
the last two characters are the internal LU number within the CU.
For the EMC DMX series, EMC CX series, and HP EVA series:
The ID that differs from the LU number in the storage system and that identifies the LU
is indicated by a hexadecimal number. The value of
iLU
consists of 32 digits. The first
13 digits of
iLU
are displayed, and periods (
...
) are displayed for the 14
th
to 16
th
digits. When the
-exlu
parameter is specified, the entire value of
iLU
is displayed.
ChaPort
3
CP
For Thunder 9200/9500V Series, Lightning 9900/9900V Series TagmaStore, and
Universal Storage Platform V:
The port number of the channel adapter, which identifies the CHA port that is mounted
on the storage system.
You can identify an actual CHA port by referencing this number from the storage
system management program.
For the Lightning 9900V Series, the port number of the channel adapter is the same as
the number shown by the SVP.
For the EMC DMX series, EMC CX series, and HP EVA series:
A hyphen (-) is displayed.
