94 Chapter 3 Creating an HDLM Environment
Number Of Trace Files : 4
Path Health Checking : on(30)
Auto Failback : off
Remove LU : off
Intermittent Error Monitor : off
HDLM Manager Ver WakeupTime
Alive xx-xx yyyy/mm/dd hh:mm:ss
HDLM Alert Driver Ver WakeupTime ElogMem Size
Alive xx-xx yyyy/mm/dd hh:mm:ss 128
HDLM Driver Ver WakeupTime
Alive xx-xx yyyy/mm/dd hh:mm:ss
License Type Expiration
Permanent -
KAPL01001-I The HDLM command completed normally. Operation name = view, completion
time =
yyyy/mm/dd hh:mm:ss
23. Use the results of the dlnkmgr command's view operation to check the version of the
installed HDLM. When 05-91 is displayed in HDLM Version, the correct version of
HDLM has been installed.
24. Use the results of the dlnkmgr command's view operation to check that the programs
are running properly. If HDLM Manager, HDLM Alert Driver, and HDLM Driver are
all Alive, all programs are running correctly.
25. After installation finishes, check the path information as described in 3.7, and make sure
that you have successfully installed HDLM in a single-path configuration.
26. Connect cables with all HBAs (multi-path configuration).
27. Check the path information as described in 3.7 to make sure that you have successfully
built a multi-path configuration.
28. Shut down the host.
29. On all the hosts comprising the cluster system, perform the operations from step 20 to
step 28.
30. Start the host individually.
31. Install MSCS.
32. Shut down all hosts after completing installation of MSCS in all hosts configured in MSCS.
33. Start the host individually.
34. Log on to the Windows system again as a member of the administrators group.
35. Make sure that the program is working normally, by examining the results of the
dlnkmgr command's view operation.
Make sure that on MSCS is displayed in Support Cluster. An example of executing
the dlnkmgr command's view operation is as follows:
>dlnkmgr view -sys
HDLM Version : xx-xx
Service Pack Version :
Load Balance : on(rr)
Support Cluster : on MSCS
Elog Level : 3
Elog File Size (KB) : 9900
Number Of Elog Files : 2
Trace Level : 0
