7

SOFTWARE SERVICE TOOL

70

ALTOSONIC V12

www.krohne.com

04/2013 - 4002643502 - MA ALTOSONIC V12 R02 en

Step 5:

Step 5:

Step 5:

Step 5: Click on the variable to select it.

Step 6:

Step 6:

Step 6:

Step 6: Click on the button pointing to the right in the panel in the middle.

Step 7:

Step 7:

Step 7:

Step 7: Put check marks in the columns for the representations you want to be logged.

Step 8:

Step 8:

Step 8:

Step 8: Click the Monitoring List Editor’s “Close” button.

Step 9:

Step 9:

Step 9:

Step 9: Click the Monitoring Configuration dialogue’s “Close” button to accept the configuration.
A confirmation dialogue appears:

Step 10:

Step 10:

Step 10:

Step 10: Click “Yes” to confirm that you want to resume monitoring the flowmeter.

Some more features to customize the logged data file

Some more features to customize the logged data file

Some more features to customize the logged data file

Some more features to customize the logged data file
(In the window “Monitoring configuration”)

Time stamp

Time stamp

Time stamp

Time stamp

The time stamp associated with each data record can be the date and time from the meter itself
or from your computer system. Select what you want from the value list associated with the box

Timestamp with”.

Start Records

Start Records

Start Records

Start Records

When starting or restarting your logging you can include a record with the names of the fields
and/or the units used. In the Excel file these will appear as column headers (one row with field
names and one row with the units used).

Log file size limitation

Log file size limitation

Log file size limitation

Log file size limitation

The size of a log file can be limited either to a maximum number of records or to a maximum
time span.
In the value list of the box “Switch file based on;” click either

• Duration, or
• Number of records

Figure 7-50: Monitoring
