SOFTWARE SERVICE TOOL

7

45

ALTOSONIC V12

www.krohne.com

04/2013 - 4002643502 - MA ALTOSONIC V12 R02 en

Step 8:

Step 8:

Step 8:

Step 8: You can:

• click the button “Use current configuration”, or
• click “Browse” to open another window This is an identical browse window as used before to

find a monitoring configuration file.
Select the file you want to use to start monitoring the next time you connect to a meter.

Step 9:

Step 9:

Step 9:

Step 9: Click “OK” to confirm the settings.

The next time you launch the program the steps 1...4 will be skipped.

7.5 Changing and saving a monitoring configuration

7.5.1 Creating a monitoring configuration

When opening the KROHNE Flowmeter Configuration and Monitoring Tool the default settings
are such that a default monitoring file is loaded and that a default user view is activated. Also the
KROHNE Flowmeter Configuration and Monitoring Tool will start logging directly. All these
features will be discussed in the next paragraphs. If due to unforeseen reasons the default start
up settings does not start up in the paragraphs below the different steps are discussed to
activate monitoring, user view and logging.

In order to modify the selection of data available for monitoring, change the monitoring
configuration.

Step 1:

Step 1:

Step 1:

Step 1: Click the button “Monitoring” to open the monitoring menu.

Step 2:

Step 2:

Step 2:

Step 2: Click the option “Configure…”.

In case a monitoring session is active the message box as below will appear.

Figure 7-16: Monitoring menu

Figure 7-17: Warning for running session
