9
TECHNICAL DATA
110
ALTOSONIC V12
www.krohne.com 04/2013 - 4002643502 - MA ALTOSONIC V12 R02 en
9.7 Flow table
Nominal size
[inch]
Q
min
Q
max
[m
3
/h]
[cf/h]
[m
3
/h]
[cf/h]
4 25 900 1000 35300
6 45 1600 2300 81200
8 75 2600 4100 145000
10 110 3900 6200 219000
12 140 4900 8200 290000
14 170 6000 9700 343000
16 210 7400 11700 413000
18 240 8500 13900 491000
20 260 9200 15700 554000
24 285 10100 21400 756000
30 450 15900 30900 1091000
36 650 23000 44500 1572000
40 800 28300 54900 1939000
42 880 31100 58000 2048000
48 1200 42400 75800 2677000
56 1600 56500 94200 3327000
64 2100 74200 117000 4132000
Qt as per ISO 17089 (Vt = 3 m/s for <12" and Vt=1.5 m/s for ≥ 12"
For piping > Sch 80 values can vary slightly.
Calculations are provided as indication, please ask KROHNE for detailed sizing.
