KROHNE ALTOSONIC V12 EN - Manual (Page 108)

9
TECHNICAL DATA
108
ALTOSONIC V12
www.krohne.com 04/2013 - 4002643502 - MA ALTOSONIC V12 R02 en
ASME 900 lb
ASME 900 lb
Nominal size [mm] H [mm] L [mm] Weight [kg]
100 1 520 400 176
150 590 600 324
200 660 600 464
250 730 750 684
300 810 900 957
350 840 1050 1190
400 890 1200 720
450 960 1350 964
500 1020 1500 1254
600 1160 1800 2200
1 Minimum Inner diameter: 80 mm (≤ sch 80).
Nominal size [inch] H [inch] L [inch] Weight [lbs]
4 1 20.47 15.75 388
6 23.23 23.62 714
8 25.98 23.62 1023
10 28.74 29.53 1508
12 31.89 35.43 2110
14 33.07 41.34 2624
16 35.04 47.24 1588
18 37.8 53.15 2126
20 40.16 59.06 2765
24 45.67 70.87 4851
1 Minimum Inner diameter: 3.15" (≤ sch 80).
