10
MODBUS PROTOCOL DESCRIPTION AND SET-UP
132
ALTOSONIC V12
www.krohne.com 04/2013 - 4002643502 - MA ALTOSONIC V12 R02 en
10.8.4 Holding Registers (read/write): Long integer (32-bit), addres range 5500-5999
7 5007 5014-5015
(2 regs)
Alarm&
Status Channel_6
A Ch_Signal_
Lost (bit 3)
Channel 6 Down:
Signal lost
Alarm flag indicating path failure (channel 6): signal lost.
8 5008 5016-5017
(2 regs)
Alarm inputs A_Temperature
OOR (bit 0)
Process
Temperature:
Out of range
Alarm flag, measured body temperature is out of range.
8 5008 5016-5017
(2 regs)
Alarm inputs A_Temperature
OVR (bit 1)
Process
Temperature:
Override value
used
Status/alarm flag indicating manual input of temperature
value overrides measured
temperature (process temperature input); will appear in
case alarm parameter nr 6 set to enabled
and Override Mode (User Control) set to enabled (mode 1
or 2); Mode 3 will not generate an alarm.
9 5009 5018-5019
(2 regs)
Status Totalisers S_Fwd_Process_
Roll (bit 1)
Rollover Totaliser
Process Forward
Status signal, totaliser has reached maximum value that
can be represented
and displayed, totalising is continued starting from zero.
9 5009 5018-5019
(2 regs)
Status Totalisers S_Rev_Process_
Roll (bit 5)
Rollover Totaliser
Process Reverse
Status signal, totaliser has reached maximum value that
can be represented
and displayed, totalising is continued starting from zero.
9 5009 5018-5019
(2 regs)
Status Totalisers S_FwdFail_
Process_Roll
(bit 9)
Rollover Totaliser
FAIL Process
Forward
Status signal, totaliser has reached maximum value that
can be represented
and displayed, totalising is continued starting from zero.
9 5009 5018-5019
(2 regs)
Status Totalisers S_RevFail_
Process_Roll
(bit 13)
Rollover Totaliser
FAIL Process
Reverse
Status signal, totaliser has reached maximum value that
can be represented
and displayed, totalising is continued starting from zero.
Relative
address Absolute address Name Parameter /
Variable
(short description)
non-Modicon Modicon-comp.
0 5500 5500-5501
(2 regs)
TestRegister
uint 32
Test Register
Relative
address Absolute address Name Parameter /
Variable
(short
description)
non-Modicon Modicon-comp. Register Bit
