SOFTWARE SERVICE TOOL
7
53
ALTOSONIC V12
www.krohne.com 04/2013 - 4002643502 - MA ALTOSONIC V12 R02 en
This window may contain multiple sheets or tabs. Each tab represents a sheet displaying a se-
lection of data, in numerical or graphical format (or both).
More sheets may be present allowing to present different sets of data or to present data in dif-
ferent formats. A particular sheet is identified by means of its name as is shown on its Tab.
3. In the window User Views, any sheet may be selected by clicking on its associated Tab.
4. Other windows may be selected to be viewed using the View menu.
7.7.1 Unformatted data
Step 1: Step 1: Step 1: Step 1: Click the button “View” on the menu bar to open the “View menu”.
Step 2: Step 2: Step 2: Step 2: Click “Monitoring Data (unformatted)…”.
An information window as below will appear as a scroll list.
The shown data is the data as currently being collected from the meter: only the values of the
variables as defined in the monitoring configuration file.
Figure 7-31: Unformatted data
