MODBUS PROTOCOL DESCRIPTION AND SET-UP
10
131
ALTOSONIC V12
www.krohne.com 04/2013 - 4002643502 - MA ALTOSONIC V12 R02 en
4 5004 5008-5009
(2 regs)
Alarm&
Status Channel_3
A Ch_Signal_
Lost (bit 3)
Channel 3 Down:
Signal lost
Alarm flag indicating path failure (channel 3): signal lost.
5 5005 5010-5011
(2 regs)
Alarm&
Status Channel_4
A Ch_Unreliable
(bit 0)
Channel 4
Unreliable
Alarm flag indicating path error (channel 4): channel
unreliable.
5 5005 5010-5011
(2 regs)
Alarm&
Status Channel_4
A Ch_Down
(bit 1)
Channel 4
Down
Alarm flag indicating path error (channel 4): channel
down.
5 5005 5010-5011
(2 regs)
Alarm&
Status Channel_4
A Ch_Deviation_
SOS (bit 2)
Channel 4 Down:
Deviation SoS
too large
Alarm flag indicating path error (channel 4): SOS deviation
too large.
5 5005 5010-5011
(2 regs)
Alarm&
Status Channel_4
A Ch_Signal_
Lost (bit 3)
Channel 4 Down:
Signal lost
Alarm flag indicating path failure (channel 4): signal lost.
6 5006 5012-5013
(2 regs)
Alarm&
Status Channel_5
A Ch_Unreliable
(bit 0)
Channel 5
Unreliable
Alarm flag indicating path error (channel 5): channel
unreliable.
6 5006 5012-5013
(2 regs)
Alarm&
Status Channel_5
A Ch_Down
(bit 1)
Channel 5
Down
Alarm flag indicating path error (channel 5): channel
down.
6 5006 5012-5013
(2 regs)
Alarm&
Status Channel_5
A Ch_Deviation_
SOS (bit 2)
Channel 5 Down:
Deviation SoS
too large
Alarm flag indicating path error (channel 5): SOS deviation
too large.
6 5006 5012-5013
(2 regs)
Alarm&
Status Channel_5
A Ch_Signal_
Lost (bit 3)
Channel 5 Down:
Signal lost
Alarm flag indicating path failure (channel 5): signal lost.
7 5007 5014-5015
(2 regs)
Alarm&
Status Channel_6
A Ch_Unreliable
(bit 0)
Channel 6
Unreliable
Alarm flag indicating path error (channel 6): channel
unreliable.
7 5007 5014-5015
(2 regs)
Alarm&
Status Channel_6
A Ch_Down
(bit 1)
Channel 6
Down
Alarm flag indicating path error (channel 6): channel
down.
7 5007 5014-5015
(2 regs)
Alarm&
Status Channel_6
A Ch_Deviation_
SOS (bit 2)
Channel 6 Down:
Deviation SoS
too large
Alarm flag indicating path error (channel 5): SOS deviation
too large.
Relative
address Absolute address Name Parameter /
Variable
(short
description)
non-Modicon Modicon-comp. Register Bit
