9
TECHNICAL DATA
106
ALTOSONIC V12
www.krohne.com 04/2013 - 4002643502 - MA ALTOSONIC V12 R02 en
ASME 300 lb
ASME 300 lb
Nominal size [mm] H [mm] L [mm] Weight [kg]
100 520 400 1 158
150 570 450 248
200 620 600 371
250 680 750 533
300 760 900 755
350 810 1050 1008
400 870 1200 520
450 920 1350 659
500 980 1500 862
600 1100 1800 1354
1 300 mm available on request.
Nominal size [inch] H [inch] L [inch] Weight [lbs]
4 20.47 15.75 1 348
6 22.44 17.72 547
8 24.41 23.62 818
10 26.77 29.53 1175
12 29.92 35.43 1665
14 31.89 41.34 2223
16 34.25 47.24 1147
18 36.22 53.15 1453
20 38.58 59.06 1901
24 43.31 70.87 2986
1 11.81" available on request.
