7
SOFTWARE SERVICE TOOL
60
ALTOSONIC V12
www.krohne.com
04/2013 - 4002643502 - MA ALTOSONIC V12 R02 en
7.8.3 Creating a new graphical presentation
Step 1:
Step 1:
Step 1:
Step 1: Click “Add Tab”.
Step 2:
Step 2:
Step 2:
Step 2: Type a name for the new tab.
Step 3:
Step 3:
Step 3:
Step 3: In the box “Type” click on the option “Trend”.
Note: Leave the “Configuration File” field empty.
Step 4:
Step 4:
Step 4:
Step 4: Click “OK”.
An empty graphic screen appears.
Step 5:
Step 5:
Step 5:
Step 5: Click the button “Configure”.
A window will open for defining the settings of the graphical presentation.
Step 1:
Step 1:
Step 1:
Step 1: Set the number of variables you want to be displayed (each variable selected for being
displayed is called a “profile”.
Step 2:
Step 2:
Step 2:
Step 2: Set the number of Y-axis’s you will need to represent the values of the variables (profiles)
you want to be displayed. This number can not be larger than the number of profiles.
Step 3:
Step 3:
Step 3:
Step 3: Set how many stacks you need. A stack is a chart area with its own X and Y axis’s. The
height of area in the graphical window will be spit in sections, each section will accommodate
one “Stack”. The number of stacks can not be larger than the number of Y-Axis’.
Step 4:
Step 4:
Step 4:
Step 4: Set the number of Y-scales you will need on the first (upper) stack.
Step 5:
Step 5:
Step 5:
Step 5: Enter this number in the tab Y-Stacks/Y-Stack0.
Do the same for any subsequent “stack”.
Step 6:
Step 6:
Step 6:
Step 6: In the tab “Profile – Process Value Mapping” specify the process value to be represented
by each profile.
Step 7:
Step 7:
Step 7:
Step 7: In the tab “Profiles” set the axis to be used for displaying the value of each profile.
Step 8:
Step 8:
Step 8:
Step 8: Adjust colours and line/marker styles according to your taste.
Step 9:
Step 9:
Step 9:
Step 9: Click “OK” .
Step 10:
Step 10:
Step 10:
Step 10: Click “Save As”.
Enter a name for the graphical presentation you just have created.
Step 11:
Step 11:
Step 11:
Step 11: Click “Save”.
INFORMATION!
It is beyond the scope of this manual to give detailed instructions about how to define the
graphical presentation. However you will be able to find your own way using the brief description
of the next steps:
