SOFTWARE SERVICE TOOL
7
59
ALTOSONIC V12
www.krohne.com
04/2013 - 4002643502 - MA ALTOSONIC V12 R02 en
Step 11:
Step 11:
Step 11:
Step 11: For the box referenced as “Property”, open the list to show the properties that can be
selected:
Label / Fieldname / Name / Full path / Parent name / Full parent path / Actual value / Average
value / Minimum value / Maximum value / Unit / Status.
Step 12:
Step 12:
Step 12:
Step 12: Click the property to be displayed.
Step 13:
Step 13:
Step 13:
Step 13: Click ”OK”.
Alternative way for steps 6...8:
Alternative way for steps 6...8:
Alternative way for steps 6...8:
Alternative way for steps 6...8:
Step 6:
Step 6:
Step 6:
Step 6: Click “User text”.
Step 7:
Step 7:
Step 7:
Step 7: Type the text string to be displayed in the cell in the field “User text”.
Step 8:
Step 8:
Step 8:
Step 8: Click ”OK”.
To adjust the appearance of a cell and its content:
To adjust the appearance of a cell and its content:
To adjust the appearance of a cell and its content:
To adjust the appearance of a cell and its content:
Step 1:
Step 1:
Step 1:
Step 1: Position the cursor on the cell to be defined.
Step 2:
Step 2:
Step 2:
Step 2: Click this cell with a click of the left mouse button.
Step 3:
Step 3:
Step 3:
Step 3: Open a menu with a right mouse click.
Step 4:
Step 4:
Step 4:
Step 4: Click “Cell Properties…”.
Continue to specify the content of any cell as you like.
Right click with your mouse in the area of the panel with the new grid to open the menu.
Click “Save…” or “Save as…” to open a dialog box to enter a name for the grid definition you just
created.
Click the “Save” button to finish.
INFORMATION!
As you have added a tab with a new grid definition, you will be reminded you have changed the
monitoring configuration file when MCST is being closed (shut down). If you accept the modified
configuration file to be saved, you will not be able to recover the monitoring configuration you
started with.
If you want to keep both the set up you started with and the modified version, you have to save the
new version with a new name before closing the program. Use the command
“
Save Monitoring
Configuration As..
”
(in File Menu) . This command stores the set up of the information sheets
contained in
“
User Views
”
as well.
