7

SOFTWARE SERVICE TOOL

56

ALTOSONIC V12

www.krohne.com

04/2013 - 4002643502 - MA ALTOSONIC V12 R02 en

Step 5:

Step 5:

Step 5:

Step 5: Click “Grid”, “Trend” or “X-Y Graph” according to your choice and then click “OK”.

Step 6:

Step 6:

Step 6:

Step 6: Click the “down” arrow to the right of the box configuration file.

Step 7:

Step 7:

Step 7:

Step 7: A list of available presentation formats will become visible. Click the file of your choice.

Step 8:

Step 8:

Step 8:

Step 8: If desired, select a format and a definition file for the second panel.

Step 9:

Step 9:

Step 9:

Step 9: Click the “OK” button.
Now the new sheet will appear with one or two panels as you have chosen.

7.8.2 Creating a new grid definition

In order to define a “grid” for presentation of data in numerical format according to your own
preferences:

Step 1:

Step 1:

Step 1:

Step 1: Click “Add Tab”.

Step 2:

Step 2:

Step 2:

Step 2: Type a name for the new tab.

Step 3:

Step 3:

Step 3:

Step 3: Select “Grid”.
Note: Leave the “Configuration File” field empty.

Step 4:

Step 4:

Step 4:

Step 4: Click “OK”.
A new tab defined as a grid will appear initially as a grey area.

Step 5:

Step 5:

Step 5:

Step 5: In order to have a visible grid displayed, the size of the grid (number of cells) has to be
defined. With a right mouse click a menu will open, click the option “Add Column(s)”:

Figure 7-33: Add tab

INFORMATION!
As you have added a new tab, you will be reminded you have changed the monitoring
configuration file when MCST is closed (shut down). If you accept the modified configuration file
to be saved, you will not be able to recover the monitoring configuration you started with.
If you want to keep both the set up you started with and the modified version, you have to save the
new version with a new name before closing the program. Use the command

Save Monitoring

Configuration As..

(in the File Menu) . This command stores the set up of the information sheets

contained in

User Views

as well.
