3-56
IM 04L61B01-01EN
3.10.2 Converting Alarm, Mark, Event, Control Mode, and Operation Log
Information
Additional information (alarm, mark, event, control mode, and operation log) in the displayed
data file can be converted and saved separately.
The example below shows how to convert alarm information.
Procedure
1
In the window, display the file that you want to convert and save the information of.
2
On the Convert menu, click Alarm To.
The Alarm To dialog box appears.
3
Specify the settings for the file conversion.
Select the file format.
Click here to select
the file name and
save destination.
Number of
lines for dividing
Path and file name
4
After you finish configuring the settings, click OK.
The data will be converted.
Explanation
Alarm, mark, event, control mode, and operation log information in display data files and
event data files can be converted and saved separately.
On the Convert menu, select the information that you want to save. Then, in the dialog box
that appears, configure the settings for the data conversion. The procedure and settings are
the same for all types of information.
Output File Type and the Number of Lines per File
File Type
Number of Lines per File
File Name Extension
Input Range
Excel97 to 2003 Workbook 10000 to 65536 xls
Excel Workbook 10000 to 1048576 xlsx
ASCII File — txt
Note
If you want to list the information in the window, you can use the Alarm/Mark window. For displaying
a list of alarms or marks, see section 3.4 . For displaying a list of events or control modes, see
section 3.5 . For displaying a list of operation log entries, see section 3.6 .
3.10 Converting Data
