2.1 Starting and Closing Universal Viewer
2.1.1 Starting Universal Viewer
Procedure
1
On the taskbar, click Start, All Programs, SMARTDAC+ STANDARD, and then
Viewer.
Universal Viewer starts. (No data is displayed initially.)
On Windows, you can associate data files to Universal Viewer so that when you double-click
a data file, the file opens in Universal Viewer.
Changing the Style
To change the screen color, on the View menu, click Style and then Light or Dark. The
default setting is Light.
The style cannot be changed in some windows and dialog boxes.
Changing the Date Format
You can change the date display format to one of the four types below. To do so, on the
View menu, click Date Format.
• YY/MM/DD
• MM/DD/YY
• DD/MM/YY
• DD.MM.YY
Decimal Point
To change the decimal point character in Universal Viewer, on the View menu, click Decimal
Point.
Toolbar, Search Bar, and Status Bar
To show or hide the bars, on the View menu, click Tool Bar, Search Bar, or Status Bar.
2.1.2 Closing Universal Viewer
Procedure
1
On the File menu, click Exit. Or, click the × button.
If you have changed the settings, the message “Save changes to file name.***?” appears.
To save the settings, click Yes.
Otherwise, click No.
