TLOG File Information Dialog Box
If the data file is a TLOG file, the TLOG File Information dialog box appears.
The following items are displayed. Use the check boxes in front of the items to specify the
items you want to print.
Item
Description
File Name
File name
Device Type
Model that sampled the data
Serial No.
Serial number of the instrument that sampled the data
File Message
File message that was added during memory sampling
Meas Ch.
Measurement channels on the instrument that sampled data
Math Ch.
Math channels on the instrument that sampled data
Interval Up
Data sampling count of the data file
TLOG Start
Start time of memory sampling
Damage Check
Data file status (normal, error)
Timer No.
Timer numbers displayed on active tabbed pages on the TLOG file
display window
Comment
Comment for printouts (up to 128 characters)
2.4 Viewing Data File Information
