Operation
What Appears on the Screen (Bold words are displayed
on the screen. Non-bold words are explanations.)
Switch in or out of daylight saving time
Switch between normal and daylight saving time
Set batch number
Set batch number (when the batch group number is invalid)
Set batch number [Batch group number] (when the batch
group number is valid)
Set lot number
Set lot number (when the batch group number is invalid)
Set lot number [Batch group number] (when the batch group
number is valid)
Writing to a batch text field
Writing to batch text field (when the batch group number is
invalid)
Writing to batch text field [Batch group number] (when the
batch group number is valid)
Second display update rate
Second display update rate
Standard display update rate
Standard display update rate
Modbus client manual recovery
Modbus client manual recovery
Modbus master manual recovery
Modbus master manual recovery
Reset timer
Timer Reset [ALL] (when all timers are reset)
Timer Reset [Timer number](when not all timers are reset)
Reset the match time timer
Match time timer reset [Timer number]
Switch on the event level switch
Event level switch on [Switch number]
Switch off the event level switch
Event level switch off [Switch number]
Event edge switch
Event edge switch [Switch number]
Change to setting mode
Change to setting mode
Change to basic setting mode
Change to basic setting mode
Change to operation mode
MoveOpe
Write to a communication input channel
Writing to communication input channel[CH Channel
number and set value (the text in the data file is displayed)]
Execute Modbus client exchange
Modbus client exchange execution[CMD Channel number
and set value (the text in the data file is displayed)]
Execute Modbus master exchange
Modbus master exchange execution[CMD Channel number
and set value (the text in the data file is displayed)]
Save settings in setting mode
Settings saved in setting mode
Load settings in setting mode
Settings loaded in setting mode
Load settings in basic setting mode
Settings loaded in basic setting mode
Clear 1
Clear 1
Clear 2
Clear 2
Clear 3
Clear 3
Clear 4
Clear 4
Calibration correction complete
Input calibration finished
Calibration correction period expiry
Due date for the next input calibration is over
Change setting mode settings
Change configuration [setting file sequence number](Set
mode)
Change basic setting mode settings
Change configuration [setting file sequence number](Basic
setting mode)
Change settings related to user
registration
Change configuration [setting file sequence number](Login
information)
Change setting mode settings and
basic setting mode settings
Change configuration [setting file sequence number](Basic
setting mode & Set mode)
Change the setting mode settings and
settings related to user registration
Change configuration [setting file sequence number](Set
mode & Login information)
Change the basic setting mode settings
and settings related to user registration
Change configuration [setting file sequence number](Basic
setting mode & Login information)
Change settings [No] (all)
Change configuration [setting file sequence number](all)
Set an alarm
AlarmSet [CH Channel number/Lvl Alarm level]
Change a calibration correction point.
Input calibration point change [CH Channel number/Pt
Calibration point
]
Change a calibration correction value.
Input calibration value change [CH Channel number/Pt
Calibration point
]
Sets an alarm delay
AlmDlaySet [CH Channel number]
Select a message
Set message [Message number]
Set the data save destination folder
FolderSet
3.6 Listing the Operation Log
