3.10 Converting Data
Group or Channel
If you select Group, enter the range of groups to convert.
If you select Channel, enter the range of channels to convert.
Additional Information
You can select whether to include alarm and mark information in the conversion.
The available options vary depending on whether you selected Group or Channel, described
above.
Group or Channel Additional Information Options
Group The first group and the last group are the same. None, With Alarm/Message
The first group and the last group are different.
None, With Alarm
Channel None, With Alarm
Data File Type
Number of Lines per File
File Type
Number of Lines per File
File Name Extension
Input Range
Excel97 to 2003 Workbook 10000 to 65536 xls
Excel Workbook 10000 to 1048576 xlsx
ASCII File — txt
Specifying the File Name and Save Destination
Click the “...” button to change the save destination or the name of the file to save the
converted data. The Change the file name dialog box appears.
The table below shows the default settings.
Setup Item Default Value
Start point Cursor A position or zero
End point Cursor B position or the last data number of the data set
Number of steps 1
Group or Channel Group
First group number Currently displayed group
Last group number Currently displayed group
First channel number Minimum channel number in the data file
Last channel number Maximum channel number in the data file
Additional information None
File Type Excel 97-2003 Workbook (*.xls)
Number of lines for dividing 65536
Converted data file name File name shown in the window
Note
• The converted data file name will vary depending on whether the file includes batch information.
If a batch number or lot number is specified, the default file name will include the number.
• Do not specify the external storage medium as the save destination because it will take a long
period of time to save the file.
• Do not specify the root directory as the save destination.
• Make sure you have enough disk space at the destination.
