1.1 Overview of Universal Viewer
This manual describes Universal Viewer.
You can use Universal Viewer to display on screen and print the following types of data that
is generated by recorders.
• Display data files
• Event data files
• TLOG data files
• Report data files (including hourly, daily, monthly, batch, and daily-custom, and free reports)
• Manual sampled data files
Multiple data files can be displayed simultaneously in separate windows. You can link and
convert data files that are displayed.
1.1.1
Files That Can Be Displayed and Their Extensions
The table below shows the types and extensions of files that Universal Viewer can display.
File Type
(Extension)
Display Type
Display
Data File
Event Data
File
TLOG
Data File
Report
Data File
Manual Sampled
Data File
*.GDS,*.DAD,*.DBD,
*.DSD,*.dds,*.cds
*.GEV,*.DAE,*.DBE,
*.DSE,*.dev,*.cev
*.dtg
*.GRE,*.DAR,*.dhr,
*.ddr,*.dwr,*.dmr
*.GMN,*.DAM,
*.dmn
Waveform Display
Yes
Yes
—
—
—
Digital Display
Yes
Yes
—
—
—
Circular Display
Yes
Yes
—
—
—
List Display
Alarm List
Yes
Yes
—
—
—
Mark List
Yes
Yes
—
—
—
Event List
1
*.cds only
*.cev only
—
—
—
(CX1000/CX2000)
Control Mode
List
1
*.cds only
*.cev only
—
—
—
(CX1000/CX2000)
Operation Log
List
2
*.DSD and *.DBD
only
*.DSE and *.DBE
only
—
—
—
(DX100P/DX200P,
DX1000/AS1, DX2000/AS1)
TLOG Display
3
—
—
*.dtg only
—
—
(CX1000/CX2000,
DX100/DX200,
DX100P/DX200P,
MV100/MV200)
Report Display
—
—
—
Yes
—
Manual Sample
Display
—
—
—
—
Yes
1 Displays files created by a CX1000/CX2000
2 Displays files created by a DX100P/DX200P, DX1000/AS1, or DX2000/AS1
3 Displays files created by a CX1000/CX2000, DX100/DX200/DX200C, DX100P/DX200P, or MV100/MV200
