3-42
IM 04L61B01-01EN
List of Operations by Model
DX100P, DX200P
Operation What Appears on the Screen (Bold words are displayed
on the screen. Non-bold words are explanations.)
Login Login
Logout Logout
Invalid password Password refused
Memory start Start memory
Memory stop Stop memory
Alarm acknowledgment Alarm ACK
Message Message
Manual sample Manual sample
Trigger Trig
Start computation Start Math function
Stops computation Stop Math function
Reset computation Reset Math data
Computation dropout acknowledgment No Math data ACK
Snapshot Snapshot
Start mail Start mail
Stop mail Stop mail
Save display data Save Display Data
Save event data Save Event Data
Load display data Load Display Data
Load event data Load Event Data
Change settings Change configuration [setting file sequence number]
Before time change Before time change
Before time adjustment Before time adjust
After time adjustment or change After change(adjust) time
Power failure Power failure occurs
Recovery after power failure Restart after Black Out
Load login information Load login information
Execute clear 1 Clear 1
Execute clear 2 Clear 2
Execute clear 3 Clear 3
Set batch number Set batch number
Set lot number Set lot number
Invalid password Password refused
Save system mode configuration Save configuration (system mode)
Save engineering mode configuration Save configuration (engineering mode)
Load system mode configuration Load configuration (system mode)
Load engineering mode configuration Load configuration (engineering mode)
Change system mode configuration Change configuration [setting file sequence number]
(system mode)
Change engineering mode configuration Change configuration [setting file sequence number]
(engineering mode)
Change the engineering mode and
system mode configurations
Change configuration [setting file sequence number]
(system mode & engineering mode)
Change login information configuration Change configuration [setting file sequence number] (Login
information)
Change the system mode configuration
and settings related to user registration
Change configuration [setting file sequence number]
(system mode & Login information)
Login to A/D calibration mode Login(A/D calibration mode)
Execute A/D calibration Execute A/D calibration
Acknowledge unauthorized access Set user refused ACK
Change password Change Password
Shutdown Shutdown
Upload file File Upload
Download file File Download
Change the number of calibration
correction points
Input calibration point change (CH Channel
number:previous number of points->new number of points)
Change the calibration correction value Set Point is changed (CH Channel number No.Calibrated
point :Value)
Reset computation Reset Math data (CH Channel number)
3.6 Listing the Operation Log
