3-48
IM 04L61B01-01EN
Displaying TLOG File Information
On the Information menu, click About Document to view information about the displayed
TLOG file.
Viewing data file information ( section 2.4 )
3.7.2 Converting a TLOG File
The sampled data in a TLOG data file can be converted and saved in Excel or ASCII format.
Use the Convert Data dialog box to specify the settings for the data conversion.
Procedure
1
On the Convert menu, click Convert Data.
The TLOG Convert Data dialog box appears.
2
Specify the settings for the file conversion.
The sampled data is saved in groups of timers. Select which timer to convert
the data of.
Select the file format.
Click here to select
the file name and
save destination.
Specify timer
numbers.
Path and file name
3
After you finish configuring the settings, click OK.
The data will be converted.
3.7 Displaying and Converting a TLOG File
