Using a Predefined Keypad Template
We have included some predefined keypad templates for each product.
To use one of the predefined keypad templates:
1. From the configuration menu, choose Keyboard Settings, then choose User-Defined
Key Editor. The User-Definable Key Assignment dialog box appears.
2. Choose the Keyboards button, then choose Open Keyboard Template. The Keyboard
File Selection dialog box appears.
3. In the Available Keyboard Files drop down list box, select the template you want to use.
4. Choose the OK button to return to the User-Defined Key Assignment dialog box. The
selected template appears.
5. Choose the Done button to return to the OITware-200 main screen.
OIT3165, OIT3185, OIT4165, and OIT4185 Predefined Keypad
Templates
24 Function Keys (3165EX1.KTF and 3185EX1.KTF)
3160 Emulation (3165EX2.KTF and 3185EX2.KTF)
Configuring the User-Definable Keypad 89
1010-0099, Rev. 07
SDF1 SDF2 SDF3 SDF4 SDF5 SDF6 SDF7 SDF8
F1 F2 F3 F4 F5 F6 F7 F8
F9 F10 F11 F12 F13 F14 F15 F16
ENTER
CLEAR
Alarm
Ack
Next
Msg
Help
Toggle
Last
Msg
Del
7
4
1
8
5
2
9
6
3
Page
Down
0
F1 F4
F2 F5
F3 F6
