INTRODUCTION

Welcome

Welcome to Maple Systems’ OIT Family Operator Interface Terminals for use with

Programmable Logic Controllers (PLCs). This powerful family of operator interface terminals

was designed to provide the human-machine interface in industrial applications. This manual

explains how the OIT Family Operator Interface Terminals operate as well as how to implement

the many available features using the OITware-200 Configuration Software.

About Your Documentation

The documentation for your OIT Family Operator Interface Terminal consists of:

Installation Manual (shipped with each OIT) — Covers the installation requirements of

your specific OIT Family Operator Interface Terminal. Each member of the OIT Family

has a manual written to its unique specifications.

OIT Family Operation Manual for PLC Protocols (shipped with OITware-200) —

Covers the general operation and features of the OIT Family when using the PLC

Protocols and implementation of those features using OITware-200.

OIT Family Operation Manual for ASCII Slave Protocol (shipped with OITware-200) —

Covers the general operation and features of the OIT Family when using the ASCII Slave

Protocol.

Controller Information Sheets (shipped with OITware-200) — Covers important

information specific to each supported protocol.

OITware-200 On-line Help — Covers the operation of OITware-200.

Conventions

You will find the following typographic conventions throughout this manual.
This

Represents

bold

Characters that you must type exactly as they appear. For example, if

you are directed to type a:setup, you should type all the bold

characters exactly as they are printed.

italic

Place holders for information you must provide. For example, if you

are directed to type filename, you should type the actual name for a

file instead of the word shown in italic type.

ALL CAPITALS Directory names, file names, key names, and acronyms.

SMALL CAPS

Non-printable ASCII control characters.

KEY1 + KEY2

A plus sign (+) between key names means to press and hold down the

first key while you press the second key.

KEY1, KEY2

A comma (,) between key names means to press and release the keys

one after the other.

Introduction

3

1010-0099, Rev. 07
