Dimensions for Computer Generated Legends
The dimensions on the following pages can be used to create legends using a computer
graphics program.
When creating (OIT3165, OIT3175, OIT3185, OIT4165, OIT4175, and OIT4185):
• Dimensions are in inches [mm].
• Recommended key size is 0.500 inches [12.7 mm] square.
NOTE:Pressing the center of the switch is critical for switch actuation.
• Background colors should extend to the upper and lower edges of the legend and to the 2
vertical lines marked “BACKGROUND.”
• All text and graphics should be within the dashed rectangle.
When creating (all models except OIT3165, OIT3175, OIT3185, OIT4165, OIT4175, and
OIT4185):
• Dimensions are in inches [mm].
• Background colors should extend to the solid lines.
• All text and graphics should be within the dashed rectangles.
When printing:
• Use only non-glossy stock which is 0.004 - 0.008 inches [0.1 - 0.2 mm] thick.
• Check printing accuracy.
