The “Setup Password:” message should appear. At this point the setup mode
keypad specified in OITware-200 is active (it can be the factory default or the
user-defined keypad).
NOTE:1. To exit configuration mode, press the CLEAR key.
2. If the “<<< Initializing >>>” message is followed by “Connecting to
PLC!”, the OIT did not enter setup mode and you need to repeat step 1.
3. If the OIT’s display remains blank and you hear a steady beeping, the OIT does not
contain a complete project and is waiting in download mode for OITware-200 to
download a project. For instructions on downloading a project from OITware-200, refer
to the Downloading an OITware-200 Project section in CHAPTER 1: Getting Started.
2. Type the setup password and then press the ENTER key. If there is no setup password,
just press the ENTER key. The “Dn/Upload Mode? YES” message should appear.
NOTE:You must start entering your password within 5 seconds, or the OIT exits setup mode.
3. Use the TOGGLE key to alternate between YES and NO.
Option Result
YES Enters download/upload mode for communication with a PC.
NO Displays “Setup Correct? YES”. Press ENTER to exit setup mode.
Press the ENTER key to accept and continue.
OIT3200, OIT3250, OIT3600, OIT4400, OIT4450, OIT5400
To enter setup mode:
1. If the OIT is already powered, press the SETUP key. Otherwise, while applying
power to the OIT, press and hold the SETUP key while the “<<< Initializing
>>>” message appears.
The “Enter Setup Password:” message should appear.
NOTE:1. To exit configuration mode, press the CLEAR key.
2. If the “<<< Initializing >>>” message is followed by “Attach
Sequence Successful!”, the OIT did not enter setup mode and you need to
repeat step 1.
3. If the OIT’s display remains blank and you hear a steady beeping, the OIT does not
contain a complete project and is waiting in download mode for OITware-200 to
download a project. For instructions on downloading a project from OITware-200, refer
to the Downloading an OITware-200 Project section in CHAPTER 1: Getting Started.
2. Type the setup password and then press the ENTER key. If there is no setup
password, just press the ENTER key. The “Download/Upload computer?
YES” message should appear.
NOTE:You must start entering your password within 5 seconds, or the OIT exits setup mode.
3. Use the TOGGLE key to alternate between YES and NO.
Option Result
YES Enters download/upload mode for communication with a PC.
NO
Displays the setup menus. Use the TOGGLE key to alternate between the
options and the ENTER key to accept an option and display the next
menu.
