OIT Model Setup Options
OIT3200
modify setup password
modify function key passwords
enable/disable screen saver
OIT3250
modify time/date
modify setup password
modify function key passwords
enable/disable screen saver
OIT3600
set display viewing angle
modify time/date
modify setup password
modify function key passwords
enable/disable screen saver
OIT4400
set display brightness
modify setup password
modify function key passwords
enable/disable screen saver
OIT4450
set display brightness
modify time/date
modify setup password
modify function key passwords
enable/disable screen saver
OIT5400
modify time/date
modify setup password
modify function key passwords
enable/disable screen saver
OIT3160, OIT4160
To enter setup mode:
1. If the OIT is already powered, press the ENTER key three times. Otherwise,
while applying power to the OIT, press and hold the CLEAR key while the
“<<< Initializing >>>” message appears. The “Setup Password:”
message should appear.
NOTE:1. To exit configuration mode, press the CLEAR key.
2. If the “<<< Initializing >>>” message is followed by “Connecting to
PLC!”, the OIT did not enter setup mode and you need to repeat step 1.
3. If the OIT’s display remains blank and you hear a steady beeping, the OIT does not
contain a complete project and is waiting in download mode for OITware-200 to
download a project. For instructions on downloading a project from OITware-200, refer
to the Downloading an OITware-200 Project section in CHAPTER 1: Getting Started.
2. Type the setup password and then press the ENTER key. If there is no setup password,
just press the ENTER key. The “Dn/Upload Mode? YES” message should appear.
NOTE:You must start entering your password within 5 seconds, or the OIT exits setup mode.
3. Use the TOGGLE key to alternate between YES and NO.
Option Result
YES Enters download/upload mode for communication with a PC.
NO Displays “Setup Correct? YES”. Press ENTER to exit setup mode.
Press the ENTER key to accept and continue.
