APPENDIX B
Slide-in Legend Templates
Some of the OIT Family Operator Interface Terminals contain clear windows that allow
you to insert your own legends to customize the text, colors and graphics of certain keys.
In some models you can also add your own logo or model identification. These legends
can be inexpensively made and are environmentally sealed when installed.
The slide-in legends can be made on any non-glossy stock between 0.004 inches
[0.1 mm] and 0.008 inches [0.2 mm] thick by using either of the following methods:
• Photocopy a blank legend and hand illustrate. Refer to the “Blank Legends for
Photocopying” section.
• Use the dimensions to create a computer generated legend. Refer to the “Dimensions for
Computer Generated Legends” section.
Refer to the Installation Manual shipped with your OIT for instructions on installing the
slide-in legends.
Maple Systems also provides key legend editor software for the OIT3165/75/85 and
OIT4165/75/85 that allows you to create customizable inserts. The program allows you
to create and edit text, bitmaps, icons, or metafiles. It also includes some standard
symbols that can be used for graphics. This software is available on our website:
www.maple-systems.com.
Blank Legends for Photocopying
The blank legends on the following pages can be photocopied and hand illustrated to create
custom slide-in legends.
When photocopying:
• Use only non-glossy stock which is 0.004 - 0.008 inches [0.1 - 0.2 mm] thick.
• Check photocopy accuracy with the printed check dimension.
When illustrating (OIT3165, OIT3175, OIT3185, OIT4165, OIT4175, and OIT4185):
• Use the tick marks to locate the switch centers. Refer to the dimension in the “Dimensions
for Computer Generated Legends” section if unsure.
NOTE:Pressing the center of the switch is critical for switch actuation.
• Recommended key size is 0.500 inches [12.7 mm] square.
• Background colors should extend to the solid lines.
• All text and graphics should be 0.070 inches [1.8 mm] within the solid lines.
NOTE:Do not affix anything to the legend using glue, tape, stickers, etc.
