Sierra SAS/SATA Protocol Suite, STX Software API Reference Manual
SCSI Command Pattern parameters 935
FID_SCSISPC3_ATTACHED_STP_TARGET_PORT // 1 bit
FID_SCSISPC3_ATTACHED_SSP_TARGET_PORT // 1 bit
FID_SCSISPC3_ATTACHED_SAS_ADDRESS // 64 bits
FID_SCSISPC3_ATTACHED_PHY_IDENTIFIER // 8 bits
FID_SCSISPC3_PAGES_SAS_ADDRESS // 64 bits
FID_SCSISPC3_MODE_PAGE_CONTROL // n bits
FID_SCSISPC3_MODE_PAGE_DESCONNECT_RECONNECT // n bits
FID_SCSISPC3_MODE_PAGE_EXTENDED //n bits
FID_SCSISPC3_MODE_PAGE_EXTENDED_DEVICE_TYPE_SPECIFIC // n bits
FID_SCSISPC3_MODE_PAGE_INFORMATION_EXCEPTION_CONTROL // n bits
FID_SCSISPC3_MODE_PAGE_POWER_CONDITION // n bits
FID_SCSISPC3_MODE_PAGE_PROTOCOL_SPECIFIC_LOGICAL_UNIT // n bits
FID_SCSISPC3_MODE_PAGE_PROTOCOL_SPECIFIC_PORT // n bits
FID_SCSISPC3_MODE_PAGE_FORMAT_DEVICE // n bits
FID_SCSISPC3_FORAMT_DEVICE_MODE_TRACKS_PER_ZONE // 16 bits
FID_SCSISPC3_FORAMT_DEVICE_MODE_ALTERNATE_SECTORS_PER_ZONE // 16 bits
FID_SCSISPC3_FORAMT_DEVICE_MODE_ALTERNATE_TRACKS_PER_ZONE // 16 bits
FID_SCSISPC3_FORAMT_DEVICE_MODE_ALTERNATE_TRACKS_PER_LOGICAL_UNIT // 16 bits
FID_SCSISPC3_FORAMT_DEVICE_MODE_SECTORS_PER_TRACK // 16 bits
FID_SCSISPC3_FORAMT_DEVICE_MODE_DATA_BYTES_PER_PHYSICAL_SECTOR // 16 bits
FID_SCSISPC3_INTERLEAVE
// 16 bits
FID_SCSISPC3_FORAMT_DEVICE_MODE_TRACK_SKEW_FACTOR // 16 bits
FID_SCSISPC3_FORAMT_DEVICE_MODE_CYLINDER_SKEW_FACTOR // 16 bits
FID_SCSISPC3_FORAMT_DEVICE_MODE_SURF // 1 bit
FID_SCSISPC3_FORAMT_DEVICE_MODE_HSEC // 1 bit
FID_SCSISPC3_FORAMT_DEVICE_MODE_SSEC // 1 bit
FID_SCSISPC3_MODE_PAGE_RIGID_DISK_GEOMETRY // n bits
FID_SCSISPC3_RIGID_DISK_GEOMETRY_MODE_NUMBER_OF_CYLINDERS // 24 bits
FID_SCSISPC3_RIGID_DISK_GEOMETRY_MODE_NUMBER_OF_HEADS // 8 bits
FID_SCSISPC3_RIGID_DISK_GEOMETRY_MODE_STARTING_CYLINDER_WRITE_PRECOMPENSATION // 24 bits
FID_SCSISPC3_RIGID_DISK_GEOMETRY_MODE_STARTING_CYLINDER_REDUCED_WRITE_CURRENT // 24 bits
FID_SCSISPC3_RIGID_DISK_GEOMETRY_MODE_DEVICE_STEP_RATE // 16 bits
FID_SCSISPC3_RIGID_DISK_GEOMETRY_MODE_LANDING_ZONE_CYLINDER // 24 bits
FID_SCSISPC3_RIGID_DISK_GEOMETRY_MODE_RPL // 2 bits
FID_SCSISPC3_RIGID_DISK_GEOMETRY_MODE_ROTATIONAL_OFFSET // 8 bits
