Sierra SAS/SATA Protocol Suite, STX Software API Reference Manual
STCompliance API 173
3. To add tests, use the AddTest command to specify test IDs:
bRetVal = ComplianceObject.AddTest( TEST_GDR_01 )
bRetVal = ComplianceObject.AddTest( TEST_GDR_02 )
...
A list of available tests and their IDs is in
ComplianceTestsEnum at the end of this section.
4. To run the tests, call the RunCompliance function:
bRetVal = ComplianceObject.RunCompliance()
5. To detach from board after the STCompliance run finishes, call the Detach function:
nErrorCode = ComplianceObject.Detach()
STCompliance API Methods
Attach
This function connects to the board.
Attach(BYTE yDefaultPort,
BSTR bstrDeviceId,
BSTR bstrSystemPath,
int* pnErrorCode)
yDefaultPort: Specifies the connection mode. Possible values are:
0x02 = USBconnection
0x04 = TCP connection
bstrDeviceId: Specifies the board ID. The first four characters specify the connection type and
the following characters specify the actual board ID. For example, for board ID = 00104CC47777,
use 020000104CC47777 for USB connection and 040000104CC47777 for TCP connection.
bstrSystemPath: Shows the path of installed software.
pnErrorCode: Returns the error code if there is an error.
Detach
This function disconnects from the board.
Detach (int* pnErrorCode);
pnErrorCode: Returns the error code if there is an error.
