Sierra SAS/SATA Protocol Suite, STX Software API Reference Manual
ISerialSCSICaptureProject 191
ISerialSCSICaptureProject
This interface class integrates all information needed for capturing, triggering, and running a
capture project.
You can define a capture project in one of two modes:
• Easy: For all methods that are related to capture items, the nStateId parameter is
defined for pre-or post-capturing as a 0, 1 value or as a Capture ID definition. For all
methods that are related to trigger items (that have ConditionExpr in the method
name), nStateId and nConditionIndex are not meaningful parameters and can pass with
any value.
• Advanced: nStateId shows a unique ID for a state, and nConditionIndex shows the Index
for a condition to trigger items.
(You can also get/set by related methods.)
NOTE: Some methods are only for Easy or Advanced mode, and the rest are for both modes.
Methods
Method Name
Method Description
Interface function for adding a
pattern to capture items.
Interface function for adding a
pattern to an expression for a
condition in advanced mode or
trigger items in easy mode.
Interface function for adding a
timer to an expression for a
condition in advanced mode.
Adds new state in advanced
mode, with default values in
capture and trigger parts, and
returns StateId of added state to
pass to all other functions of this
ID.
Copies and pastes a state in a
position.
Copies a state to the clipboard to
paste in a position.
Returns the type of project:
Analyzer or Exerciser/Analyzer
