Sierra SAS/SATA Protocol Suite, STX Software API Reference Manual
Using Analyzer API 46
Using Analyzer API
To use analyzer APIs, you must create an instance of a capture project object, then you can
create a new capture project or open a saved one. After these steps, the capture project is
ready for modifying and running. After running the project, you can stop the project and upload
and create the sample.
• Initialize a capture project object
• Create a new Analyzer capture project
• Run an Analyzer capture project
• Stop an Analyzer capture project
• Upload and create the sample file
• Open a saved Analyzer capture project
• Modify an existing Analyzer capture project
o
Set trigger mode/strategy
o
Add trigger pattern
o
Remove trigger pattern
o
Set capture mode/strategy
o
Add capture pattern
o
Remove capture pattern
o
Exclude/include pattern items
o
Set memory usage parameters
 Put entire memory
 Put segmented memory
 Put partial memory
 Set trigger position in memory
o
Set output sample file path
o
Set port configuration
• Summary
• Set a timer to check status of the hardware after run
