Sierra SAS/SATA Protocol Suite, STX Software API Reference Manual
SAS Layer definition 869
INSTRUCTION_TYPE_IF_DEVICE_TYPE,
INSTRUCTION_TYPE_IF_PAYLOAD_BUFFER,
INSTRUCTION_TYPE_IF_ABORT_NCQ_COMMAND,
INSTRUCTION_TYPE_IF_HOST_QUEUE_COUNT,
INSTRUCTION_TYPE_SATA_PM_RESPONSE,
INSTRUCTION_TYPE_SATA_IF_PM_REQUEST,
INSTRUCTION_TYPE_POWER_ON,
INSTRUCTION_TYPE_POWER_OFF,
SAS Layer definition
typedef enum {
LAYER_LINK
= 0x01, //00000000 00000001
LAYER_IDLE = 0x02, //00000000 00000010
LAYER_TRANSPORT = 0x04, //00000000 00000100
LAYER_ATA_COMMAND = 0x08, //00000000 00001000
LAYER_SCSI_COMMAND = 0x10, //00000000 00010000
LAYER_SMP_COMMAND = 0x20, //00000000 00100000
LAYER_TASK_COMMAND = 0x40, //00000000 01000000
LAYER_DATA_REPORT = 0x80, //00000000 10000000
LAYER_QUEUE_COMMAND = 0x0100, //00000001 00000000
LAYER_OOB_SEQUENCE
= 0x0200, //00000010 00000000
} SASLayerEnum;
Link mode packet definition
LINK_TYPE_STP_FRAME = 0
LINK_TYPE_OPEN_ADDRESS_FRAME = 1
LINK_TYPE_SSP_FRAME = 2
LINK_TYPE_SMP_FRAME = 3
LINK_TYPE_BUS_CONDITION = 4
LINK_TYPE_PRIMITIVE = 5
LINK_TYPE_IDENTIFY_ADDRESS_FRAME = 6
LINK_TYPE_RESERVE_ADDRESS_FRAME = 7
LINK_TYPE_ZONE_BROADCAST_ADDRESS_FRAME = 8
