Sierra SAS/SATA Protocol Suite, STX Software API Reference Manual
Using Target/Device Emulator API Functions 122
STDMETHOD (ErInjSATASigSetInsertPrimitive) (
/*[in]*/ BOOL bEnable, /*[in]*/ int nPrimitiveType,
/*[in]*/ PrimitiveTypeEnum ePrimitiveGroupType,
/*[in]*/ short iOffsetFromFrameStart,
/*[in]*/ short iRepeatCount, /*[out]*/ int * pnRetVal);
STDMETHOD (ErInjSATASigSetFillByteForReservedField) (
/*[in]*/ BYTE yFillByte, /*[out]*/ int * pnRetVal);
STDMETHOD (ErInjSATASigSetFrameLengthError) (
/*[in]*/ BOOL bEnable,
/*[in]*/ FrameLengthErrorTypeEnum eFrameLengthError,
/*[in]*/ int nFrameLength, /*[out]*/ int * pnRetVal);
Usage ->
();
Return Value None
Description Call the respective functions to set error injection on SATA Signature options of
Modify Settings
Modifying the settings page of a Target Emulator project depends on the type of the project: SAS or SATA. Modify
the project settings and then the common settings of SAS and SATA. The following sections discuss how to
modify SAS-specific Target Emulator settings, SATA-specific Target Emulator settings, and common configuration
settings for a Target Emulator Project.
Modify SAS Specific Configuration Settings
The SAS Specific Target Emulator settings include:
• SAS Address
• Logical Block Size
• Linked Command Expired Time
• OOB Signal Settings-COMSAS (Advanced)
• Time outs (Advanced)
The corresponding functions and prototypes are:
Modify Settings – SAS Specific Function Name
SAS Address Put_SASAddress ()
Logical Block Size Put_LogicalBlockLength ()
Linked Command Expired Time Put_LinkedCommandExpiredTime ()
