Sierra SAS/SATA Protocol Suite, STX Software API Reference Manual

ISerialSCSICaptureProject 301

SetATACommandCapturePatternLBAMode

SetATACommandCapturePatternLBAMode (

int nStateId,

long lPatternIndex,

BOOL bLBAMode);

Inputs
int nStateId

ID for a state in advanced mode and Capture ID

) in easy mode.

long lPatternIndex

Target capture pattern index.

BOOL bLBAMode

Target ATA Command captures pattern Mode (Mode is CHS or LBA).

Return Value
None.

Remark
Sets the type of an ATA command pattern that was added in capture items. This mode may be

LBA or CHS. In LBA mode, a LBA parameter is defined, and you can set/get its value, but in CHS

all related parameters (Sector Number, Cylinder Low, Cylinder High) are defined and you can

set/get their value.

See Also
