Sierra SAS/SATA Protocol Suite, STX Software API Reference Manual
How to Navigate through Trace File 148
How to Navigate through Trace File
Navigating through a Trace/Sample file involves:
• Load a Trace File and Build View
o
Load a Trace File
o
Build View for Packet Navigation
• Navigate through Trace File
o
Extract Packet Information
o
Navigate Through Packets
• Filter Packets
o
Set Filter Data
o
Apply Filter
• Search/Find Packets
• Summary
Load a Trace File and Build View
Load a Trace File
To load/open a saved sample file, use the Open () function of Extraction.
int nIsOpenSuccess = m_SerialSCSIExtraction -> Open (bstrFileName);
CSerialSCSIExtraction::Open ()
Prototype
int Open (_bstr_t bstrFileName);
Usage -> Open ();
Inputs _bstr_t bstrFileName: BSTR format of the sample file path
Return Value Success/failure status of the method execution
Description Call the Open () function of Extraction interface to load any saved sample file.
Build View for Packet Navigation
To build a Data-View or Packet-View for trace file navigating, call their respective functions,
such as BuildDataView or BuildPacketView of Extraction Interface.
BOOL bRetVal = m_pSASExtraction->
BuildDataView (CEI_FRAME_VIEW_TYPE, TRUE, TRUE);
BOOL bRetVal = m_pSASExtraction->BuildPacketView ();
