Sierra SAS/SATA Protocol Suite, STX Software API Reference Manual
ATA Command Pattern parameters 908
ID_PARAMETER_VENDOR_FIRST_DWORD,
ID_PARAMETER_VENDOR_OTHER,
ID_PARAMETER_LBA,
ATA Command Pattern parameters
FID_ATACOMMAND__VALUE_7_0 // 8 bits
FID_ATACOMMAND_PROTOCOL //
FID_ATACOMMAND_IN // n bits
FID_ATACOMMAND_NORMALOUT // n bits
FID_ATACOMMAND_ERROROUT // n bits
FID_ATACOMMAND__FEATURES // 8 bits (na)
FID_ATACOMMAND__LOGICALSECTORSPERLOGICALTRACK // 8 bits
FID_ATACOMMAND__SECTORCOUNT // 8 bits
FID_ATACOMMAND__SECTOROFFSET // 8 bits
FID_ATACOMMAND__ERROR // 8 bits
FID_ATACOMMAND__LBALOW // 8 bits
FID_ATACOMMAND__LBAMID // 8 bits
FID_ATACOMMAND__LBAHIGH // 8 bits
FID_ATACOMMAND__LBA // 28 bits
FID_ATACOMMAND__NATIVEMAXADDRESS // 28 bits
FID_ATACOMMAND__SECTORNUMBER // 8 bits
FID_ATACOMMAND__CYLINDERLOW // 8 bits
FID_ATACOMMAND__CYLINDERHIGH // 8 bits
FID_ATACOMMAND__HEADNUMBER // 4 bits
FID_ATACOMMAND__COMMAND // 8 bits
FID_ATACOMMAND__REGNUM // 8 bits
FID_ATACOMMAND__RESERVED // 8 bits
FID_ATACOMMAND__PORTNUM // 4 bits
FID_ATACOMMAND__NUMBEROFSECTORPERSTOBEREAD // 8 bits
FID_ATACOMMAND__NA // UnKnown
FID_ATACOMMAND__DEV // 1 bits (4)
FID_ATACOMMAND__LBABIT // 1 bits (6)
FID_ATACOMMAND__MED // 1 bits (0)
FID_ATACOMMAND__DMA // 1 bits (0)
