Sierra SAS/SATA Protocol Suite, STX Software API Reference Manual
Using Analyzer API 65
The following table lists the Patttern Types for the PatternTypeEnum Option (for Capture
Pattern) and their corresponding functions to set the required parameters:
PatternTypeEnum Index Functions to set parameters
ID_PATTERN_TYPE_FIS
ID_PATTERN_TYPE_FIS_PATTERN
(STP Frame) SetFISCapturePattern ()
SetCapturePatternParameterValu
eBy
OptionId ()
SetCapturePatternDirection ()
ID_PATTERN_TYPE_ADDRESS_FRA
ME
(Address Frame)
SetAddressFrameCapturePattern
()
SetCapturePatternDirection ()
ID_PATTERN_TYPE_SMP_FRAME
(SMP Frame) SetSMPFrameCapturePattern ()
SetCapturePatternDirection ()
ID_PATTERN_TYPE_SSP_FRAME
(SSP Frame) SetSSPFrameCapturePattern ()
SetCapturePatternDirection ()
SetCapturePatternSSPCDBType ()
SetCapturePatternSSPDataPres ()
SetCapturePatternSSPUseHashAdr
ess ()
ID_PATTERN_TYPE_DATA_PATTER
N
(Data Pattern)
SetDataCapturePattern ()
SetCapturePatternDataOffset ()
SetCapturePatternDirection ()
SetCapturePatternIsNot ()
SetCapturePatternParameterValu
e ()
ID_PATTERN_TYPE_PROTOCOL_ER
RORS
(Protocol Errors)
SetProtocolErrorCapturePattern ()
SetCapturePatternDirection ()
SetCapturePatternParameterValu
e ()
