79
CATC F IRE I NSPECTOR 2.01 C HAPTER 5
User’s ManualCATC Trace Fil es
Expand All Fields or Transactions
Expands all fields or transactions of the current type.
Collapse All Fields or Transactions
Collapses all fields or transactions of the current type.
Export Data
Opens the Export Data dialog. For more information, see “Exporting Trace Files” on
page 87.
View Type Fields
Opens the View Fields dialog, which is described on page 75. Please refer to specific
protocols in Section 5.2.2 “Transaction-Level Decoding” to find out which transaction row
fields contain the View Type Fields command.
5.2.5 Cell Context Menu Commands for Traffic Generation Files
These additional commands may be available for traffic generation (.txg) files only. Please
see “Editing Tools in FireInspector” on page 96 for details about these commands.
Edit Packet
Opens an Edit Packet dialog that allows you to edit the packet data.
Delete Packet
Deletes the packet.
Insert Packet
Opens the Insert Packet dialog.
Change all...Dest_IDs
Opens the Change Destination ID Throughout File dialog.
5.2.6 Trace View Menus
The Trace view pop-up menu contains commands for general display and viewing options.
This makes it easy to make changes to the display and quickly find the information you are
looking for.
To access the Trace view menu in a Trace file:
• Right-click on the background of the Trace display. The Trace view menu will pop up.
The Trace view pop-up menu provides the following commands:
