119
CATC F IRE I NSPECTOR 2.01 C HAPTER 9
User’s Manual Reports
To configure font and color settings for bus usage graphs:
Step 1
Click the View Settings icon on the Bus Utilization toolbar and select
Fonts & Colors... from the drop-down menu.
The View options dialog will open.
Step 2 Select fonts for the graph titles and axes from the drop-down font lists.
Step 3
Set the point size, and, optionally, bold and/or italic for each font you
selected in Step 2.
Step 4
Select colors for the graph titles, axes, backgrounds and grid lines from the
drop-down color chart.
Note: Choosing Other... from the chart opens the Colors dialog. For details about
this dialog, please see “Color Tool/Colors Dialog” on page 44.
Step 5
Click OK to apply the settings.
Graph Area Menu
The Bus Utilization Graph Area menu provides options for customized viewing of
individual graphs within the display window.
To access the menu, right-click anywhere in a graph's display area, or left-click on the
options arrow on the upper right corner of the graph's display frame.
9.5.3 Data Settings
Data settings allow you to configure which data is displayed and how it is displayed in bus
usage graphs.
Table 9-2: Graphs Area Menu
Command Descripton
Undo zoom Undoes the last zoom command.
Zoom to Trace view Repositions the graph to reflect data from the currently visible portion
of the source Trace file.
Fit to graph area Fits the entire graph into the display area.
Y Scale Type > Linear or
Logarithmic Sets the Y scale type to linear or logarithmic.
Hide Closes the graph.
Remove Deletes a custom-defined graph.
Properties Opens the Graph Area Properties dialog. Please refer to “Graph Area
Properties” on page 121 for more information.
