125
CATC F IRE I NSPECTOR 2.01 C HAPTER 10
User’s ManualPrinting and Exporting Fil es
C
HAPTER
10: P
RINTING AND
E
XPORTING
F
ILES
FireInspector can print Trace (.fdb and .txg) files, tree (.tsf) files, and bus utilization graph
(.bmp) files, and can export the contents of Trace files.
10.1 Printing Files
The following file types can be printed from FireInspector: Trace files, bus topology tree
files, and bus utilization graphs.
10.1.1 Print a Trace file
Step 1
Select File > Print from the menu bar or click the Print icon on the
toolbar.
The Print Packets/Transaction dialog will open.
Step 2 Enter a starting packet or transaction on the “From” line, and an ending
packet or transaction on the “To” line of the dialog. Clicking the Reset Range
to Whole Trace button sets the From and To entries to include all of the
packets in the Trace.
Note: If there are no transactions in the Trace file, the drop-down list of transactions
will not be available.
Step 3
Click OK to print specified range.
10.1.2 Print a tree file
Step 1
Select File > Print from the menu bar or click the Print icon on the toolbar.
The Print Topology Tree dialog will appear.
Step 2
Click Yes to print the file.
10.1.3 Print a bus utilization graph
Step 1 Click the Print icon on the bus utilization toolbar.
The visible portion of the graph(s) will be printed. If there is more than one
graph open, the visible portion of each graph will printed on its own page.
10.2 Exporting Files
FireInspector can export the contents of traffic recording Trace (.fdb) files to four different
formats:
• Packet (Trace) view format (.txt)
