64
CATC F IRE I NSPECTOR 2.01 C HAPTER 5
User’s ManualCATC Trace Fil es
Note: HAVi protocol recording and decoding is an optional licensed feature that must be purchased from
CATC.
Audio/Video Control (AV/C) Transactions
Some AV/C transaction row fields are listed in the following table.
View Type Fields in AV/C Transaction Rows
Several of the fields in AV/C transaction rows contain a View Fields command that allows
you to see the contents of the data structures.
Left-click* on the field header to access the cell context menu, which contains the View
Fields commands. Selecting the command opens a View Fields dialog, which contains the
data laid out according to the AV/C specification.
*If the option Right click cell context menu is checked on the General tab of the Display Options dialog,
then the cell context menu is opened by right-clicking. See Section 5.1.1, “General Display Options” on
page 42 for more information.
For more information about the View Fields dialog, please see “View Fields Dialog” on
page 75.
These are the fields that contain View Fields options:
• Command: contains the fields of the AV/C command frame.
• Response: contains the fields of the AV/C response frame.
Table 5-5: Fields in AV/C transaction rows*
Field Heading Description
CTS The value of the CTS field (0 = AV/C) of the AV/C frame.
Controller The value of the source_id field in the first packet of the transaction.
Target The value of the destination_id field in the first packet of the
transaction.
su_type The value of the subunit_type (su_type) field of the AV/C frame.
su_id The value of the subunit_ID (su_id) field of the AV/C frame.
Command The value of the ctype field of the AV/C frame.
Opcode The value of the opcode field of the AV/C frame. When the response
frame opcode matches the command frame opcode, then only the
command opcode is displayed in the Trace.
Response The value of the response field of the AV/C frame.
Consists of The number of IEEE 1394 transactions that make up the AV/C
transaction.
*Not all possible fields are listed. The remaining AV/C fields are determined by the opcode and may
vary widely.
