78
CATC F IRE I NSPECTOR 2.01 C HAPTER 5
User’s ManualCATC Trace Fil es
Time From Marker
Opens the All Markers dialog (see page 84). Select a marker and then press the Go To
button. The Timing and Bus Usage calculator opens and displays the total time between the
chosen marker and the packet used to access the command.
Format > Numeric Format
Allows you to change the format of the numbers in the Trace. Possible format choices are
Hexadecimal, Decimal, Binary, ASCII, and Most Significant Bit (MSB) to Least Significant
Bit (LSB) or LSB to MSB.
Color > Color Chart
Allows you to change the field color. Selecting Other at the bottom of the chart opens the
Colors dialog. For more information about using the dialog, please reference “Color
Tool/Colors Dialog” on page 44.
Hide
Hides all occurrences of the field. Note that hidden cells can be revealed using the Trace
view menu.
Search for the next Type
Goes to the next occurrence of the packet type.
Reconstruct Topology Tree
Generates a topology tree from the packets. Please see “Reconstructing Bus Topology” on
page 106 for more information.
Reconstruct Configuration ROM
Reconstructs the Configuration ROM data and displays it in the Configuration ROM dialog.
Please reference “Reconstructing Configuration ROM” on page 108 for more information
about this operation.
Find response
Goes to the response packet for the current packet. This command is available only for Read
Request packets.
View Data Block
Opens the Raw Data dialog. For details about this dialog, please see “Raw Data Dialog” on
page 75.
Expand/Collapse Field or Transaction
Expands or collapses the field or transaction.
